KNIFE GATE VALVE
The AVK 702‑10‑103 (AVK002AX) is a lug/wafer knife gate valve engineered for wastewater applications, featuring a non-rising stainless-steel stem operated via a handwheel. Designed for durability and minimal maintenance, it boasts a full and plain bore, self-cleaning action, and a plane-bottom profile to prevent sediment buildup. Constructed from ductile iron with anti-corrosion coatings, it includes a replaceable NBR+PTFE packing gland, bolstered by a steel-sprung U-seal. Suitable for a temperature range of 0–80 °C (up to 90 °C), it handles pressures up to 10 bar, with standard testing at approximately 15 bar. Approved under PED and ATEX standards and available in DN 50–600 sizes, it complies with EN‑558‑1 and EN‑1092‑2 norms. The valve’s robust build—stainless gate, sturdy stem, captive bolts—and modular design ensure long service life in demanding environments.
Description
| PARAMETER | SPECIFICATIONS |
| Nominal Diameter (DN) | 50–600 mm |
| Pressure Rating (PN) | PN 10 (optionally PN 16 in some DN) |
| Temperature Range | 0 °C to +80 °C (suitable for wastewater up to +90 °C) |
| Valve Type | Lug/Wafer knife gate valve, non-rising stem with handwheel |
| Flow Characteristics | Bi-directional, full bore, plane-bottom, no body cavities |
| Body Material & Coating | Ductile iron (GJS‑400‑15), 100–150 μm UV-resistant polyester (RAL 5017); e-coated as alternative |
| Gate/Stem Material | Stainless steel 316 |
| Stem Sealing | Replaceable top packing gland; NBR+PTFE with steel-sprung U‑seal |
| Standards & Approvals | EN 558‑1 Series 20; EN 1092‑2 flange; PED 2014/68/EU; ATEX 2014/34/EU |
| Test Pressure | 1.5 × operating pressure ≈ 15 bar |
| Operating Pressure | 10 bar (PN 10) |
| Temperature Rating | 0–80 °C (typical), up to 90 °C depending on version |
| Typical Face-to-Face | EN 558‑1 series 20 (e.g., 43 mm at DN50) |
